Features
- Fully Confirm IS 2189
- Zone Wise Fire, Fault LED Indication
- Zone Isolation Facility
- Auto Dialer Attachable Facility
- External Switch for Reset, Silence, and Lamp Test
- Inbuilt Buzzer
- 16 x 2 Line LCD Display
- Inbuilt Battery Charger & Battery Space
- Operates on 230V AC, 50Hz AC Supply
- Potential Free Contact Facility
- Supports Up to 20 Devices in Each Zone
- Mains AC Fail, Fuse, Charging, and Low Battery Indication
- Zone Wise Hooter Option Along with Common Hooter
Technical Specification
| Power I/P | 230V AC / 24V DC Optional |
| Power Consumption | 45 Watt |
| End of Line | 4.7kΩ |
| No. of Zones | 6, 8 |
| Detection O/P Supply | 24V DC |
| Hooter O/P Supply | 24V DC |
| Operating Temperature | 0°C to 60°C |
| Operating Humidity | 95% (Non-Condensing) |
Mechanical Specification
| Cabinet Type | MS |
| Colour | Off White / Red / Dark Grey |
| Paint | Powder Coating |
| Knock Out | 18 mm |
| Dimensions | 350 × 260 × 110 mm |
| Weight | 4 kg (Without Battery) |
