Intelligent Monitor Card Designed for Valve & Door Switch Tracking.
Our Addressable Monitor Interface tracks third-party dry contacts. It monitors sprinkler flow switches, fire door position logs, or gas system pressure valves and reports status changes back to the main console.
- Supervised Input Line: Detects open/short loop states via end-of-line resistors.
- Built-in Line Isolator: Integrated isolator card protects communication loops.
- Status LED Indicators: Red alarm LED and yellow fault LED on module face.
- Simple Addressing: Easily addresses using rotary dial decimal switches.
Addressable Input State Tracking
The Glyptic Monitor Module links non-addressable sensors directly to the addressable loop. By checking the end-of-line resistor status continually, it confirms switch contacts, reporting valve triggers, security door bypasses, or line cuts instantly.
| Operating Voltage Range | 16V DC to 28V DC (Loop powered) |
|---|---|
| Quiescent Current | ≤ 250 µA @ 24V DC |
| Input Monitoring Line | Supervised using 4.7K Ohm End-of-Line resistor |
| Integrated Line Isolator | Yes, trips at 1.5A short-circuit current threshold |
| IP Protection Rating | IP30 standard (IP65 waterproof case available) |
| Dimensions | 120mm x 80mm x 40mm |
Construction Quality
Molded in grey flame-retardant polycarbonate. Features a snap-fit faceplate and integrated screw-down terminals to ensure clean terminal wiring connections.
