| Operating Voltage |
10–32 VDC
|
| Quiescent Current |
60 µA @ 24V |
| Alarm Current |
7 mA (Without Remote Indicator)
19 mA (With Remote Indicator) |
| Fire LED |
Red, Flashes Every 10 Seconds Normally
Red Steady Glow After Alarm
|
| Sensor |
Photoelectric Diode |
| Detection Principle |
Light Scattering & Rate of Rise + Fixed Temperature |
| Environment Temperature |
-10°C to +60°C
|
| Relative Humidity |
5% – 95% RH
|
| Material Enclosure |
Polycarbonate
|
| Dimensions |
Diameter 100 × 100 mm Circular × 52 mm Depth (Approx.)
|
| Weight |
150 g (Approx.)
|
| Viewing |
360° Dual LED
|
| Additional Features |
Fast Alarm Reporting, Electronics-Free Base |
