Specification
| Operating Voltage | 10–32 VDC |
| Quiescent Current | 60 µA @ 24V |
| Alarm Current | 7 mA (Without Remote Indicator) 19 mA (With Remote Indicator) |
| Fire LED |
Red, Flashes Every 10 Seconds Normally Red Steady Glow After Alarm |
| Sensor | Thermistor Fixed with ROR (Rate of Rise) |
| Detection Principle | Light Scattering & Rate of Rise + Fixed Temperature |
| Environment Temperature | -10°C to +60°C |
| Relative Humidity | 5% – 95% RH |
| Material Enclosure | Polycarbonate |
| Dimensions | Diameter 100 × 100 mm Circular × 52 mm Depth (Approx.) |
| Weight | 150 g (Approx.) |
| Viewing | 360° Dual LED |
| Additional Features | Fast Alarm Reporting, Electronics-Free Base |
